Introduction

In modern cloud architectures, real-time IoT data processing is one of the most common and powerful use cases. Devices continuously generate sensor data, telemetry, logs, and events that must be processed instantly and stored reliably.

In this tutorial, we will build a complete serverless real-time IoT streaming pipeline using:

  • Amazon Web Services IoT Core
  • Amazon Web Services Kinesis Data Streams
  • Amazon Web Services Lambda
  • Amazon Web Services S3
  • Amazon Web Services DynamoDB

The architecture will look like this:

IoT Core
   ↓
IoT Rule
   ↓
Kinesis Data Stream
   ↓
Lambda
  ↙      ↘
S3     DynamoDB

This setup is commonly used in:

  • Smart devices
  • Industrial IoT
  • Vehicle telemetry
  • Real-time analytics
  • Sensor monitoring systems

Video Tutorial

What We Will Build

The flow works like this:

  1. IoT devices publish MQTT messages to AWS IoT Core
  2. IoT Rule captures the messages
  3. Messages are sent to Kinesis Data Stream
  4. Lambda consumes records from Kinesis
  5. Lambda stores:
    • Raw data into S3
    • Processed/indexed data into DynamoDB

AWS Services Used

ServicePurpose
AWS IoT CoreReceive MQTT messages
Kinesis Data StreamsReal-time streaming buffer
AWS LambdaProcess streaming records
Amazon S3Store raw JSON payloads
DynamoDBStore structured data

Step 1 — Create S3 Bucket

Open: Amazon S3 Console

Create a bucket.

Example:

iot-raw-data-demo

This bucket will store raw JSON payloads received from IoT devices.

Step 2 — Create DynamoDB Table

Open: DynamoDB Console

Create a table:

SettingValue
Table Nameiot-data
Partition KeydeviceId
Sort Keytimestamp

This table will store processed device data for quick querying.

Step 3 — Create Kinesis Data Stream

Open: Kinesis Service

Create a stream:

SettingValue
Stream Nameiot-stream
Capacity ModeOn-demand

Kinesis acts as a scalable real-time streaming buffer between IoT Core and Lambda.

Step 4 — Create Lambda Function

Open: AWS Lambda Console

Create function:

SettingValue
Nameiot-kinesis-processor
RuntimeNode.js 20 +

Lambda Code index.mjs

import { S3Client, PutObjectCommand } from "@aws-sdk/client-s3";

import { DynamoDBClient } from "@aws-sdk/client-dynamodb";

import {
    DynamoDBDocumentClient,
    PutCommand
} from "@aws-sdk/lib-dynamodb";

const s3 = new S3Client({});

const dynamo = DynamoDBDocumentClient.from(
    new DynamoDBClient({})
);

const BUCKET_NAME = "iot-raw-data-rajat";

export const handler = async (event) => {

    console.log("EVENT:", JSON.stringify(event));

    for (const record of event.Records) {

        // Decode base64 data
        const payload = Buffer.from(
            record.kinesis.data,
            'base64'
        ).toString('utf-8');

        console.log("Payload:", payload);

        const data = JSON.parse(payload);

        // Save to DynamoDB
        await dynamo.send(new PutCommand({
            TableName: "iot-data",
            Item: {
                deviceId: data.deviceId,
                timestamp: Date.now(),
                temperature: data.temperature,
                humidity: data.humidity
            }
        }));

        // Save raw data to S3
        await s3.send(new PutObjectCommand({
            Bucket: BUCKET_NAME,
            Key: `raw/${Date.now()}.json`,
            Body: JSON.stringify(data),
            ContentType: "application/json"
        }));

        console.log("Saved successfully");
    }

    return {
        statusCode: 200
    };
};

Step 5 — Configure Lambda Permissions

Inside Lambda:

Configuration → Permissions

Attach these IAM policies:

Policy
AmazonKinesisReadOnlyAccess
AmazonS3FullAccess
AmazonDynamoDBFullAccess
AWSLambdaBasicExecutionRole

These permissions allow Lambda to:

  • Read Kinesis records
  • Upload files to S3
  • Write items to DynamoDB
  • Write logs to CloudWatch

Step 6 — Add Kinesis Trigger

Inside Lambda:

Add Trigger → Kinesis

Choose:

  • Stream: iot-stream
  • Starting Position: LATEST

Now Lambda will automatically execute whenever data arrives in Kinesis.

Step 7 — Create IoT Rule

Open: AWS IoT Core Console

Navigate:

Message Routing → Rules

Create a rule.

SQL Query:

SELECT * FROM 'device/data'

This listens to MQTT topic:

device/data

Step 8 — Send Data to Kinesis

Choose action:

Write a message into an Amazon Kinesis stream

Configuration:

SettingValue
Streamiot-stream
Partition Key${topic()}

Create a new IAM role when prompted.

Step 9 — Add IoT IAM Policy

Open: AWS IAM Console

Locate the IoT role and attach this inline policy:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": [
        "kinesis:PutRecord",
        "kinesis:PutRecords"
      ],
      "Resource": "*"
    }
  ]
}

This allows IoT Core to push messages into Kinesis.

Step 10 — Publish Test MQTT Data

Inside IoT Core:

MQTT Test Client

Subscribe to:

device/data

Publish message:

{  "deviceId": "sensor-1",  "temperature": 27,  "humidity": 68}

Step 11 — Verify the Pipeline

Check Lambda Logs

Open: Amazon CloudWatch Console

Verify:

  • Lambda execution logs
  • Successful processing
Check DynamoDB

Open table:

iot-data

You should see inserted device records.

Check S3

Open bucket:

iot-raw-data-demo

You should see uploaded JSON files.

Understanding the Data Flow

IoT Core

Receives MQTT messages from devices.

Example topic:

device/data

Kinesis Data Streams

Acts as a real-time scalable buffer.

Benefits:

  • Handles spikes in traffic
  • Enables parallel processing
  • Supports multiple consumers

Lambda

Processes streaming data automatically.

Tasks:

  • Decode Base64 payload
  • Parse JSON
  • Store data

S3

Stores raw unprocessed payloads for:

  • Backup
  • Analytics
  • Auditing
  • Data lakes

DynamoDB

Stores structured indexed records for:

  • Fast querying
  • Dashboards
  • APIs
  • Real-time applications
